OVERVIEW
The Act series coreless servos utilize a fully CNC-machined aluminum protective case and benefit from metal gears. These high-voltage servos are capable of supporting up to 8.4V and offer both high speed and torque performance.
The Act series servos are available in a range of models to support different torques and Speeds depending on your needs. These servos are ideally matched to models especially where power, reliability, and precision are required.
FEATURES
- High Durability with Metal Gear
- All-aluminum CNC-machined Protective Case
- 8.4V High Voltage Capability, Offering Excellent Torque with Optimal Speed Performance.
- Integrated Dual Precision Ball Bearing and Potentiometer
SPECIFICATIONS
| Act Coreless 5400 Series High-Voltage Servos | ||||||
| DIMENSION | 40×20×39mm (L×W×H) | |||||
| WEIGHT | 80g | |||||
| HORN SPLINE | Φ6 25T | |||||
| STALL CURRENT | 4.7A@6.0V / 5.8A@7.4V / 6.6A@8.4V | |||||
| OPERATING VOLTAGE RANGE | 4.8~8.4V | |||||
| REFRESH RATE | 1520us/333Hz | |||||
| PERFORMANCE | TORQUE|SPEED @6.0V | TORQUE|SPEED @7.4V | TORQUE|SPEED @8.4V | |||
| S5412H | 22 kgf.cm 305.5 Oz-in |
0.07 sec/60° | 27 kgf.cm 375 Oz-in |
0.06 sec/60° | 30 kgf.cm 416.6 Oz-in |
0.05 sec/60° |
| S5414H | 47 kgf.cm 652.7 Oz-in |
0.12 sec/60° | 55 kgf.cm 763.8 Oz-in |
0.10 sec/60° | 63 kgf.cm 874.9 Oz-in |
0.08 sec/60° |
| S5415H | 53 kgf.cm 736 Oz-in |
0.15 sec/60° | 63 kgf.cm 874.9 Oz-in |
0.12 sec/60° | 71 kgf.cm 986 Oz-in |
0.10 sec/60° |
