OVERVIEW
TFR4B is support CPPM and RSSI (PWM) output – If CH3 and CH4 are connected by a jumper, CH1 will output CPPM for CH1~CH8, and CH2 will output RSSI (PWM).
TFR4B has two selectable failsafe setting options.
FEATURES
1) CPPM and RSSI (PWM) output – If CH3 and CH4 are connected by a jumper, CH1 will output CPPM for CH1~CH8, and CH2 will output RSSI (PWM)
2) Lighter weight and physically smaller
3) Two selectable failsafe setting options (use native failsafe on radio side or set failsafe on TFR4-B side)
SPECIFICATIONS
| Compatibility |
|
||||
| Dimension | 42*17*7mm | ||||
| Weight | 4.6g/4g (naked) | ||||
| Operating Voltage Range | 3.5~10V | ||||
| Number of Channels | 4ch | ||||
| Operating Temperature Range | -10℃~ 80℃ |
